Blasting machine ( exploder ) “VOLYN”

410$

The machine is designed to create an electric current of the required magnitude in the electrical network (hereinafter referred to as the network) and initiate EDP (electrodetonators of normal sensitivity or their analogues). According to the principle of operation, the machine belongs to the condenser type. The energy to create an electric current is accumulated in the internal capacitor of the machine for a relatively long period of time (seconds) and is transmitted to the network for a relatively short period of time (milliseconds). The machine is powered by a built-in Li-Ion battery (hereinafter referred to as the battery).

Category:

BLASTING MACHINE  ( EXPLODER ) “VOLYN” is a mobile electronic device designed for initiation of EDP (electrodetonators of normal sensitivity or their analogues). The form factor of the device is optimal and ergonomic, designed based on the requirements and needs of sappers, representatives of engineering and geological works in the mining industry.

The set of BM “VOLYN” includes:

  • a device with an equipped battery;
  • USB charging cable;
  • case;
  • network charger;
  • car charger;
  • passport of the product.

Optionally, it can be equipped with a bag, the cost of the product is discussed individually.

The guaranteed number of electrical impulses delivered to the explosive network (explosions) from one charge of the battery (battery) under normal conditions, no less 1200
The guaranteed minimum number of electrical impulses delivered to the explosive network (explosions) from one battery charge at the maximum operating temperatures, cycles, no less 600
Capacity of the storage capacitor, μF (with a tolerance of ±10%) 2
The voltage on the storage capacitor, V, is not less 1500
The maximum permissible number of serially connected electrodetonators in EVM, pcs. 100
The total resistance of the EVM, Ohm, when the detonators are connected in series is no more 300
The maximum permissible number of parallel-connected electrodetonators in EVM, pcs. 5
The total resistance of the EVM, Ohm, when the detonators are connected in parallel is no more 15
The time of putting the machine into operation for issuing an explosive impulse, s, no more 6
The range of operating temperatures of the surrounding environment during operation, °C from –25 to +40
The range of ambient temperature limits during operation, °С -30 – +45
Class of protection against dust and moisture according to DSTU EN 60529 ІР65
Weight of the machine, kg, no more 0.37
